Many of the industrial products HUI manufactures have a powder coated paint finish. As with any finish applied to any product, the powder coating we apply needs to be tested to ensure that the finish is going to last. The following is a brief description of some of the tests we commonly use to validate that our powder coated finishes are in-tolerance, properly cured and ready to stand up to the usage and environmental conditions your products will be used in.
Adhesion Tests
Crosshatch
The crosshatch test is designed to test the adhesion of the powder coating to the metal substrate. It’s performed by cutting a crosshatched grid pattern into the coating all the way down to the substrate. A special pressure-sensitive tape is then applied to the cross-hatched area and then removed quickly at close to an 180-degree angle . The area is then inspected to see if any of the coating lifted away from the substrate.
Mandrel Bend
This test checks the elasticity and the adhesion of the powder coating to the substrate. A cured sample panel is placed into a small device that bends the panel over onto itself. The coating should not crack or lose adhesion in the area of the bend.
Impact Test
Similar to the mandrel bend test, the impact test deforms a sample panel in order to test the adhesion of the powder coating. The sample panel is placed into the testing machine where an anvil is dropped onto it to produce a deep depression. Here again, the powder coated finish should not crack or lose adhesion to the substrate in the impact area.
Durability Test
Salt Spray Test
This is a corrosion-resistance test and is performed by scribing a line or “X” into the surface of a finished powder coated panel. The panel is then placed into a fog chamber where a corrosive mist is applied to it. The panel is taken out of the chamber at set time intervals and the distance that the coating has “crept” away from the scribed line is measured and recorded. If the amount of creep does not exceed the allowable distance in the predetermined time intervals, the panel passes the test.
Cure and Finish Tests
MEK Rub Test
This test is used to ensure proper cure of the powder coating to the substrate. Methyl Ethyl Ketone (MEK) is applied to a surface of the part or panel, then rubbed with a cotton swab. The area is observed for degradation or loss of paint adhesion to the substrate.
Color Match
Once our powder coated parts have cured and cooled off after being in the bake oven, the finished color is compared to an approved color chip sample. This visual inspection is the most common and quickest method to check the color. If there is a variance, the color can then be measured using a color spectrophotometer to provide data that can be compared to a known sample and tolerance range for the specific color.
Gloss Measurement
The gloss of a finished powder coated part is validated by measuring the specular reflection of its surface. This test is performed using a gloss meter, which shines a light onto the surface of the part at a fixed angle, then measures the amount of light reflected off it. If the measurement is out of tolerance, it may be an indication that the powder coating has not cured properly.
Coating Thickness Test
To achieve the best coating performance, each powder has a specified thickness range it must be applied within. HUI takes this measurement at two different stages during the powder coating process. Our powder room technician uses a dry mil gauge to take the first measurement right after the part comes out of the powder booth. The technician can then relay to the painters if they’re applying the correct amount of powder onto the parts. This immediate feedback is beneficial because it catches possible light- or heavy-coated parts before the powder is cured and it’s too late to fix the problem. After the parts have cured, the mil thickness is checked again to verify the coating thickness is within tolerance for the specified powder.
At HUI, we validate our painting processes to ensure that an industrial product’s finish stays beautiful and durable so that you receive the finish you desire. If you have questions about powder coating or you’re ready to start manufacturing your industrial project, contact Ryan Arnold at rarnold@huimfg.com.
